FRAME: Silverback Custom, 700c Aluminum City Sport Frame, 6061 Butted, Tapered 1-1/8” – 1.5“ Headtube, Key Join Smoothwelds, 135mm QR Dropouts, Fender & Rack Mounts and Replaceable Alloy Hanger
-
FORK: Silverback Carbon Fiber Aero, Tapered Alloy steerer, Postmount brake mount, Integrated cable guide
-
REAR SHOCK: N/A
-
RIMS: Alex Black Dragon, Alloy Double Wall, 32H, Stainless Steel Eyelets, Polyurethane Rimtape, Black, Custom Sector Decals
-
HUBS: Rear: Shimano FH-CX75, Centrelock, Adjustable cup and cone angular contact bearings, cassette, Silver Front: Shimano HB-CX75, Centrelock, Adjustable cup and cone angular contact bearings, Silver
-
TYRES: Vittoria Rubino Pro, 700x25c, Kevlar Bead, 150TPI
-
STEM: Sector Reach Alloy, 3D Forged Alloy, Ahead, 40/44/48.5cm L: 80mm; 52.5cm L: 90mm; 56cm L: 100mm; 7° Rise ∮31.8mm, Black Bolts, Black finish
-
HANDLEBAR: Sector Plane Alloy, W: 620mm; Back Sweep: 9° x ∮31.8mm; 6061 Butted Oversized
-
SEATPOST: Sector Level Alloy, ∮31.6mm x 350mm; 1 Piece Alloy, Black
-
SADDLE: Sector City Series, Cr-Mo rails, w/Comfort foam
-
BRAKE SET: Shimano BR-T445, Resin Pad, Hydraulic caliper, 160mm Rotor F+R, Centre Lock. Brake Levers: Shimano BL-T445
-
SHIFTERS: Shimano SL-RS700, 2x11 Trigger, Silver/Grey
-
FRONT DERAILLEUR: Shimano 105 FD-5800, Double, Band-type, Black
-
REAR DERAILLEUR: Shimano 105 RD-5800, 11 Speed, Black
-
CASSETTE: Shimano CS-5800, 11 Speed, 11-28T
-
CRANKSET: Shimano FC-RS500, 50/34T, 40/44cm L: 170mm; 48.5/52.5cm L: 172.5; 56cm L: 175mm, Black
-
BOTTOM BRACKET: Shimano SM-BB5500, External Hollowtech II
FRAME SIZES |
XXS |
XS |
S |
M |
L |
XL |
A |
SEAT TUBE C/T |
360 |
400 |
440 |
485 |
525 |
560 |
B |
TOP TUBE |
505 |
520 |
545 |
570 |
590 |
610 |
C |
HEAD TUBE ANGLE |
70° |
70° |
71° |
71.5° |
71.5° |
72° |
D |
SEAT TUBE ANGLE |
75° |
75° |
75° |
74° |
73.5° |
73° |
E |
CHAINSTAY LENGTH |
435 |
435 |
435 |
435 |
435 |
435 |
F |
BB HEIGHT |
276 |
276 |
276 |
276 |
276 |
272 |
G |
HEAD TUBE LENGTH |
105 |
120 |
135 |
155 |
180 |
205 |
H |
WHEELBASE |
1007 |
1023.5 |
1040 |
1051 |
1066.5 |
1076
|
